SN.	OEM Part No	Part No.	Description English	Qty.
*	3106 8256 80	G3106 8256 80	Valve Compl.	1
1	3106 8256 00	G3106 8256 00	Valve	1
2	3106 2698 00	G3106 2698 00	Button	1
3	3106 8255 00	G3106 8255 00	Valve sleeve	1
4	0653 1041 00	G0653 1041 00	Gasket	1
5	0517 1414 00	G0517 1414 00	Ball	1
6	3000 0353 00	G3000 0353 00	Spring	1
7	3122 0368 00	G3122 0368 00	Piston rod	1
8	3106 6757 00	G3106 6757 00	Pin	1
9.1	3122 0390 00	G3122 0390 00	Valve pin	1
9.2	3006 7751 00	G3006 7751 00	Pin	1
9.2	3006 2700 00	G3006 2700 00	Spring	1
9.4	3122 0389 00	G3122 0389 00	Nut	1
9.5	3106 7441 00	G3106 7441 00	Sleeve	1
9.6	3106 7446 00	G3106 7446 00	Driver	1
9.7	3106 7647 00	G3106 7647 00	Sliding piece	1
9.8	3122 0443 00	G3122 0443 00	Spring	1
9.9	3106 7648 00	G3106 7648 00	Washer	1
9.10	3106 7442 00	G3106 7442 00	Guide socket	1
9.11	0666 4093 00	G0666 4093 00	Seal ring	1
9.12	0335 2132 00	G0335 2132 00	Circlip	1
9.13	3122 0388 00	G3122 0388 00	Spindle	1
9.14	3106 8626 00	G3106 8626 00	Nut	1
9.15	0517 1414 00	G0517 1414 00	Ball	1
9.16	3051 2003 00	G3051 2003 00	Spring	1
9.17	3122 0204 00	G3122 0204 00	Hard wheel	1
10	9000 0342 00	G9000 0342 00	Nipple	1
11	9000 0337 00	G9000 0337 00	Wing nut	1
12	9000 0323 00	G9000 0323 00	Hose nipple	1
*	3122 0027 80	G3122 0027 80	Guide socket, compl.	1
13	3122 0027 00	G3122 0027 00	Guide socket	1
14	3122 0003 00	G3122 0003 00	Bushing	1
15	3122 0030 00	G3122 0030 00	Piston	1
16	3122 0029 00	G3122 0029 00	Packing	1
17	3122 0031 00	G3122 0031 00	Washer	1
18	3000 1348 02	G3000 1348 02	Nut	2
19	3122 0042 00	G3122 0042 00	Cylinder	1
20	0268 3108 00	G0268 3108 00	Nut	1
21	1444 3367 00	G1444 3367 00	Bolt	1
22	3122 0028 00	G3122 0028 00	End piece	1
*	3106 7349 80	G3106 7349 80	Support, compl.
23	3106 7349 00	G3106 7349 00	Support	1
24	3005 5114 07	G3005 5114 07	Pin	1
25	3101 3693 00	G3101 3693 00	Stud	1
26	3122 0034 00	G3122 0034 00	Handle	1
27.1	3001 3676 01	G3001 3676 01	Machine attachment	1
27.2	3001 3684 01	G3001 3684 01	Bolt	1
27.3	3001 3685 00	G3001 3685 00	Washer	1
27.4	3001 3597 01	G3001 3597 01	Feed mount	1
27.5	3000 9140 21	G3000 9140 21	Spring	1
27.6	3001 3677 01	G3001 3677 01	Machine holder	1
27.7	3000 1349 02	G3000 1349 02	Nut	2
27.8	3005 5114 07	G3005 5114 07	Pin	1
27.9	3106 9778 00	G3106 9778 00	Nut	2
27.10	3000 1345 00	G3000 1345 00	Nut	2
27.11	3101 3680 01	G3101 3680 01	Clamp	2
27.12	3106 9777 00	G3106 9777 00	Bolt	2
