SN	OEM Part No	Part No	Description	Quantity
1	3115 2475 00	G3115 2475 00	Drill Retainer	1
2	3115 2068 00	G3115 2068 00	Retainer Pin	1
3	0108 1359 00	G0108 1359 00	Slotted Spring Pin (Ø 8 X 32 mm)	1
4	3111 0057 00	G3111 0057 00	Rubber Buffer	1
5	3111 0056 00	G3111 0056 00	Buffer Plate	1
6	3111 0053 00	G3111 0053 00	Front Head	1
7	3111 0062 00	G3111 0062 00	Cap Nut	2
8	3111 0023 00	G3111 0023 00	Conical Spring	2
9	3111 0020 00	G3111 0020 00	Pawl	2
10	3111 0066 00	G3111 0066 00	Drill Chuck (Hexagon 22 X 108 mm)	1
11	3111 0024 00	G3111 0024 00	Driver	1
12	3111 0019 00	G3111 0019 00	Ratchet Wheel	1
13	3111 0017 00	G3111 0017 00	Intermediate Part	1
14	3111 0050 00	G3111 0050 00	Piston	1
15	3111 0015 00	G3111 0015 00	Cylinder	1
16 (17-19)	3111 0047 80	G3111 0047 80	Cover, Complete (SL No. 17,18,19)	1
17	3111 0047 00	G3111 0047 00	Cover	1
18	3111 0048 00	G3111 0048 00	Bushing	1
19	0108 3241 00	G0108 3241 00	Pin (Ø 4 X 22 mm)	1
20	3111 0049 00	G3111 0049 00	Main Valve	1
21	3115 2096 00	G3115 2096 00	Throttle Housing	1
22	3115 1967 00	G3115 1967 00	Valve	1
23	3115 2086 00	G3115 2086 00	Throttle Lever	1
24	3111 0044 00	G3111 0044 00	Inlet Nipple	1
25	3111 0043 00	G3111 0043 00	Adapter	1
26	3000 5825 02	G3000 5825 02	Adapter	1
27	3115 1543 00	G3115 1543 00	Hose Nipple (19 mm)	1
28	9000 0338 00	G9000 0338 00	Wing Nut	1
29	3115 0811 00	G3115 0811 00	Handle Bracket	1
30 (31-32)	3310 0569 80	G3310 0569 80	Handle, Complete (SL No. 31,32)	1
31	-	-	Handle	1
32	3310 0572 00	G3310 0572 00	Bushing	2
33	0108 1360 00	G0108 1360 00	Pin (Ø 8 X 36 mm)	2
34	3111 0061 00	G3111 0061 00	Side Bolt	2
35	3000 0121 00	G3000 0121 00	Gasket	1
36	3111 0045 00	G3111 0045 00	Flushing Tube	1
37	0663 2124 00	G0663 2124 00	O-Ring (Ø 17.3 X 2.4 mm)	1
38	3111 0046 00	G3111 0046 00	Plug	1
39	-	-	Data Plate	1
